◆品牌優勢特點 Product features
1. 設置新創意,自己的外觀形象,壞保成果好;
2. 可控式風暴破乳器,能將可爐料磨具與細小有害氣體破乳,好的爐料磨具以后適用;
3. 主耍零配件適用創新型國外進口組件,在使用平均時間長;
4. 處理工件產品接觸面不均;
5. 多工裝夾具定制;實際系統管理員可時候實際工作噴砂。給出買家標準,要選擇半重新或重新 ;可按潛在客戶想要制作廠!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆適用人群區間 Applicable scope
產品,租賃金屬外殼,音響聲音開關按鈕,漢堡包烤盤等水平面及方體類件的噴砂加工生產。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆主要的的技術性能參數 Main technical parameters
機械設備機型 Model |
STR-多工位輸送式噴砂機 |
整個設備長度 Complete machine size(mm) |
3000×1000×1700 |
的工作三維空間 Work space(mm) |
2000×1000×800 |
外傳輸的尺寸 Conveying the size(mm) |
500×1000×1000(2件) |
除塵設備箱尺寸規格 Dedust box sizes(mm) |
600×600×1800 |
分離器三相電機 Separator motor |
220V 50HZ 550W |
溶合器風口尺寸 Separator air volume |
8.5m3/min |
壓縮視頻環境源 Compressed air source |
2-8bar(kg/cm2) |
噴槍 Spray gun |
2把 |
照明 Floodlight |
兩盞30W防爆設備燈 |
機械設備容量 Machine weight |
550kg |
